Ctrl
】
+
【
UP
】
: Overall upward translation of the margin line for the current tooth position
【Ctrl】+ 【Down】: Overall downward translation of the margin line for the current tooth
position
【
Alt
】
+ Mouse wheel
：
Adjust the overall translation threshold;
【
Ctrl
】
+
【
Z
】：
Undo margin line editing for the current tooth position
【Ctrl】+【Y】:Redo margin line editing for the current tooth position
Clear the margin line
Clear the current margin line: Click the clear margin line button in the panel to clear the margin line
Clear all the margin lines: open the ALL switch under the margin line button, then all the margin
lines can be cleared (This feature is enabled by default)
A10. Save the margin line: complete the scan to save the edited margin line.
4.3.3 Camera panel
Function: Adjust the projector brightness and switch camera view
(1) Adjust projector brightness automatically
A1.Click
【
Automatic
】
A2. Single click at the model on the camera window, the software will adjust the appropriate
brightness according to the position.
(2) Adjust the projector brightness Manually
A1. Drag the bar or use the mouse wheel to adjust the projection brightness when the mouse is
over the drag bar
A2.Click
【
+
】
and
【
-
】
to adjust the projector brightness slightly
You can observe that the area on the model turns red in the camera view window
during the adjustment process. The red area indicates that the brightness is too high
and the appropriate brightness standard is that there is not too much red on the
model area to be scanned.
