Installation Guide for Uplogix Local Managers 15
GPRS cellular modem
Follow these steps to install the GPRS cellular modem:
1. Power off the Local Manager.
2. Install an activated SIM card on the modem.
3. Remove the option slot cover, align the modem carrier card with the internal rails, and
slide the modem into place.
4. Feed wire into the option slot compartment, align modem cover plate with the option
slot screw holes, and replace the screws.
5. Install antenna.
6. Power on the Local Manager.
CDMA cellular modem
Follow these steps to install the CDMA cellular modem:
1. Power off the Local Manager.
2. Note the Electronic Serial Number (ESN) on the modem, as this will be needed in
order to activate the modem on your carrier’s network.
3. Remove the option slot cover, align the modem carrier card with the internal rails, and
slide the modem into place.
4. Feed wire into the option slot compartment, align modem cover plate with the option
slot screw holes, and replace the screws.
5. Install antenna.
6. Power on the Local Manager.
