Maintenance
Operation Manual Page 9
M
AINTENANCE
WARNING
!
!
Never perform service while the platform is elevated.
H
YDRAULIC
F
LUID
The hydraulic fluid reservoir is located in the chassis door.
Figure 5: Hydraulic Fluid Reservoir and Dipstick
NOTE: Never add fluid if the platform is elevated.
C HECK H YDRAULIC F LUID
1. Make sure that the platform is fully lowered.
2. Open the chassis door.
3. Remove the filler cap from the hydraulic fluid reser-
voir.
4. Check the fluid level on the dipstick on the filler cap.
5. Add the appropriate fluid to bring the level to the FULL
mark. See “Specifications” on page14
Filler Cap
