Illustrated Parts Breakdown - General Assembly
AB38 Bi-Energy PARTS MANUAL
General Assembly
1
Item Part Description QTY.
1 501845-000 FUEL FILTER MOUNTING PLATE 1
2 501798-000 AIR INLET, BOTTOM DUCT 1
3 501790-000 AIR FILTER, ACCESS PANEL 1
4 501797-000 AIR INLET, TOP DUCT WELDMENT 1
5 501779-000 PROTECTION FRAME 1
6 501785-000 HYDRAULIC TANK COVER 1
7 501793-000 ALTERNATOR MOUNTING PLATE 1
8 501761-000 HYDRAULIC BLOCK MOUNTING BRACKET 1
9 500260-001 HYDRAULIC TANK 1
10 501765-000 DIESEL TANK MOUNTING BRACKET 1
11 501792-000 RECTIFIER MOUNTING BRACKET 1
12 501760-000 ENGINE COMPARTMENT DIVIDER PLATE 1
13 501787-000 SIDE PLATE (HYDRAULIC TANK) 2
14 501795-000 PUMP MOTOR MOUNTING BRACKET 1
15 501791-000 ENGINE BATTERY TRAY 1
16 501786-000 EXHAUST BLANKING PLATE 1
17 501847-000 ELECTRICAL BOX MOUNTING PLATE 1
18 501769-000 EXHAUST 1
19 501824-000 EXHAUST BRACKET 1
20 501844-000 VIBRATION MOUNT 6
20 501814-000 VIBRATION BUMPERS 6
21 501789-000 CHASSIS ENGINE SIDE PANEL 1
22 501774-000 ENGINE COVER 1
23 501743-000 ENGINE 1
24 501788-001 HINGE, ENGINE COVER (LH) 1
25 501788-000 HINGE, ENGINE COVER (RH) 1
