Upright AB38 User Manual

Page 14 Operation Manual
Specifications
S
PECIFICATIONS
ITEM METRIC IMPERIAL
Duty Cycle 45% of 8 hour shift
Platform Size 0.7 m x 1.3 m (inside guardrails)
Max. Platform Capacity
CE V ersion
200 kg 440 lbs
ANSI Version
215 kg 475 lbs
Max. Number of Occupants 2 People 2 People
Height
Maximum Working Height
13.45 m 44.12 ft
Maximum Platform Height
11.45 m 37.56 ft
Min. Platform Floor Height
0.65 m 2.13 ft
Max. Working Outreach 6.10 m 20.00 ft
Platform Height at
Maximum Outreach 5.40 m 17.72 ft
Stowed Dimensions
Length
4.04 m 13.25 ft
Width
1.71 m 5.61 ft
Height
2.00 m 6.56 ft
Ground Clearence 0.13 m 0.43 ft
Wheel Base X Guage 2.00 m x 1.27 m 6.56 ft x 4.16 ft
Rotation 362 degrees non-continuous 362 degrees non-continuous
Gross Weight-CE Version 3670 kg 8091 lbs
Gross Weight-ANSI Version 4108 kg 9057 lbs
Gross Weight-CE Rotator 3800 kg 8378 lbs
Drive Speed Stowed 0 - 4 km/h 0 - 2.49 mph
Drive Speed Elevated 0 - 0.72 km/h 0 - 0.45 mph
Maximum Gradeability 36% 36%
Inside Turning Radius 0.40 m 1.31 ft
Outside Turning Radius 2.66 m 8.73 ft
Power Source 48V DC 4kw, 8 x 6V 220Ah Batteries 48V DC 5.4 HP, 8 x 6V 220Ah Batteries
System Voltage 48V 48V
Battery Charger 48V 25A 220/110VAC 50/60 Hz 48V 25A 220/110VAC 50/60 Hz
(OR)
Kubota OC95 (6.5KW @ 3000rpm) suppling 80Amps @ 48v
Hydraulic Tank Capacity 25 Litres 6.5 Gallons US
Max. Hydraulic Pressure 145 bar 2105 psi
Hydraulic Oil ISO #46 ISO #46
Lift System 2 Double acting lift cylinders with 2 Double acting lift cylinders with
Lock Valves and Manual Emergency Lock Valves and Manual Emergency
Lowering Facility. Lowering Facility.
1 Double Acting Telescopic Cylinder 1 Double Acting Telescopic Cylinder
Control System One handed Proportional Joystick One handed Proportional Joystick
Operating Energy Efficient Motor Operating Energy Efficient Motor
Control System (MOS 90) Control System (MOS 90)
Wheels/Tyres 400 mm Diameter Steel Disc Wheel 15.75 inch Diameter Steel Disc Wheel
with Solid all Surface tyres with Solid all Surface tyres
Braking Automatic Spring Applied Automatic Spring Applied
Hydraulic Release Hydraulic Release
Sound Pressure Level at 84 db(A) 84 db(A)
Kubota OC95 Diesel Engine specs
Fuel Diesel Diesel
Fuel consumption 0.8L Per Hour 0.8L Per Hour
Power 6.5kw @ 300rpm 6.5kw @ 300rpm
Diesel Tank Capacity 12L (Mounted Seperately) 12L (Mounted Seperately)
Alternator 80Amps @ 48v 80Amps @ 48v
