Upright AB38 - General Description; Platform and Components

Introduction
Operation Manual Page 3
I
NTRODUCTION
This manual covers the AB38 Bi-Energy Aerial Work Platform. This manual must be stored on the machine
at all times.
Read, understand and follow all safety rules and operating instructions before attempting to operate the
machine.
G
ENERAL
D
ESCRIPTION
Figure 1: AB38 Bi-Energy
1. Platform
WARNING
!
!
DO NOT use the maintenance platform
without guardrails properly assembled and
in place
2. Entry Bar
3. Elevating Assembly
4. Platform Controls
5. Manual Case
6. Lower Controls
7. Hydraulic Reservoir
8. Level Sensor
9. Batteries
10. Emergency Lowering Valves
11. Battery Charger
1
2
3
4
5
6
7
8
9
10
10
11
