Page 6-14
Illustrated Parts Breakdown -6.1-Introduction
MX15/19
Chassis Assembly
065602-020
ITEM PART DESCRIPTION QTY.
1 065620-010 CHASSIS WELDMENT X15 1
2 065678-000 BRAKE PIVOT WELDMENT 1
3 011753-012 COTTER PIN 1/8 X 11/2 5
4 065685-000 BRAKE ACTUATOR WELDMENT 2
5 065690-010 YOKE WELDMENT R.H. X15 1
6 065691-010 YOKE WELDMENT L.H. X15 1
7 101152-001 HYDRAULIC TANK ASS’Y X15 1
8 065933-000 POWER UNIT 1
065933-006 MOTOR
065933-007 PUMP
065933-008 BRUSHES
9 065371-000 STEERING CYLINDER 1
065371-011 SEAL KIT
10 011781-020 BEARING 4
11 027931-072 BEARING 2
12 027931-059 BEARING 4
13 027931-022 BEARING 4
14 101125-001 DRIVE MOTOR 2
101125-010 DRIVE MOTOR SEAL KIT
15 065743-000 DRIVE WHEEL 2
16 065744-020 IDLER WHEEL 2
18 011273-006 NUTHEX 3/8-16 JAM 2
19 065657-001 TRAY WELDMENT L.H. 1
20 066604-000 BRAKE CYLINDER 1
066604-010 SEAL KIT
066604-015 SPRING
21 027931-071 BEARING 2
23 013315-010 RING, RETAINING "E" 2
25 063728-001 SLIDE BLOCK 4
26 011935-003 FITTING, 45× 6MBH-6MJ 4
27 011254-032 SCREW HHC 3/8-16 x 4 4
28 011782-010 THRUST WASHER 1/2 X 7/8 X 3/16 LG 2
29 026553-004 RVT POP 3/16 DIA. .25-.38 GRIP 8
30 011287-008 SCREW SET 3/8-16 x 1 2
31 011252-008 SCREW HHC 1/4-20 UNC X 12
32 065756-000 FRONT TRIM COVER 1
35 064754-000 SPACER LATCH 2
36 101120-122 VALVE BLOCK ASS’Y 1
37 065650-001 TRAY WELDMENT R.H. X15/19 1
39 010149-000 FUSE BLOCK 1
40 010148-001 FUSE 175 AMP 1
42 065736-000 WHEEL COVER L.H. X15/19 1
44 065737-001 FORKLIFT POCKET 1
45 065733-000 THRUST PAD 1/4 UHMW 2
47 065800-000 WELDMENT, STEER PIN 2
48 065731-000 STEER LINKX15/19 2
49 065732-000 STEER GUIDE 2
50 065984-000 HEAT SINK 1
51 063973-001 VALVE N.C. 2
52 066322-000 CYLINDER LINK 1
55 066096-016 SCREW 1/2-13UNC SQ HD x 2 1
56 018183-058 TUBE 1-3/8 O.D. x 1/8 WALL x 5/8 LG 1
58 011934-001 FITTING 4MBH-4MJ 5
60 011248-002 LOCK NUT8-32 2
61 05299-000 LATCH TOGGLE 2
62 011708-006 SCREW MACH RD HD 8-32 x 3/4 2
64 011252-008 SCREW HHC 1/4-20 X 14
65 011248-004 LOCK NUT1/4-20 20
66 011240-004 WASHER FLAT STD 1/4 10
67 011252-006 SCREW HHC 1/4-20 x 3/4 5
68 011709-008 SCREW MACH HD RD 10-24 x 1 2
69 011248-003 LOCK NUT 10-24 2
70 011248-005 LOCK NUT 5/16-18 5
71 011240-005 WASHER FLAT STD 5/16 14
72 011934-003 FITTING 90 6MBH-4MJ 1
73 011254-008 SCREW HHC 3/8-16 X 14
76 011256-026 SCREW HHC 1/2-13 x 3-1/4 8
77 011240-008 WASHER FLAT STD 1/2 8
78 011248-008 LOCK NUT1/2-13 8
79 011941-012 FITTING 8MB-12MJ 1
80 011937-007 FITTING 90 12FJX-12MJ 1
81 011934-004 FITTING 90 6MBH-6MJ 1
83 015945-016 NUT SLOTTED HEXJAM 1-14 UNF 2
84 011754-012 COTTER PIN 5/32 x 1-1/2 2
85 011757-010 COTTER RUERING 4
86 011240-006 WASHER FLAT STD 3/8 20
87 011248-006 LOCK NUT3/8-16 15
89 011254-020 SCREW HHC 3/8-16 x 2-1/2 2
91 011848-041 CLEVIS PIN 3/4 x 2 1
92 063329-008 WASHER, FLAT 1" I.D. 2" O.D. 2
94 011273-008 NUT1/2-13JAM HEX 1
96 011252-040 SCREW HHC 1/4-20 UNC X 53
97 012553-012 SCREW, SOCKET HD 1/4-20UNC X 1-1/2 2
99 063559-006 SHOULDER BOLT 3/8 x 2 1
100 066807-001 ALARM DUAL TONE 1
101 065683-001 I/O MOUNT ANGLE 1
102 011252-006 SCREW RD HD 6-32 X 3/4 2
103 011848-036 CLEVIS PIN 5/8 X 21/4 2
104 011848-019 CLEVIS PIN 3/4 X 21/2 2
105 011780-040 BEARING 5/8 X 13/16 X 1/2 LG 4
107 014996-010 WASHER 5/8 SAE FLAT PLATED 8
108 010122-001 SOLENOID 1
109 065970-001 CYLINDER DEPRESSION MECHANISM 2
065970-011 SEAL KIT
110 065971-000 DEPRESSION RAIL WELDMENT L.H. 1
111 065971-001 DEPRESSION RAIL WELDMENT R.H. 1
114 065709-001 CIRCUIT BOARD 1
115 065708-001 MOTOR CONTROL 1
118 011940-018 FITTING 12MP-8MJ 1
119 05154-001 FILTER ASSY 1
05154-002 FILTER ELEMENT
120 065359-000 LADDER SUPPORT WELDMENT 1
121 011254-008 SCREW HHC 3/8-16UNC X 14
ITEM PART DESCRIPTION QTY.
