Upright TM12 Service Manual

Service Manual Page i
F OREWORD
This manual contains instructions for the maintenance of the machine. Referring to the Operator Manual
will aid in understanding the operation and function of the various components and systems of the
machine, and help in diagnosing and repair of the machine.
All information contained in this manual is based on the latest product information available at the time of
printing. We reserve the right to make changes at any time without notice. No part of this publication may
be reproduced, stored in retrieval system, or transmitted, in any form by any means, electronic, mechani-
cal, photocopying, recording, or otherwise, without the prior written permission of the publisher. This
includes text, figures and tables.
This manual consists of five (5) parts.
O PERATOR M ANUAL
A copy of the Operator Manual that is stored on every UpRight Aerial Work Platform.
S ECTION 1 - G ENERAL I NFORMATION
Contains generic information relevant to all UpRight Aerial Work Platforms.
S ECTION 2 - S ERVICE AND R EPAIR
Detailed information specific to this UpRight Aerial Work Platform.
S ECTION 3 - T ROUBLESHOOTING
Causes and solutions to typical problems.
S ECTION 4 - S CHEMATICS
Electric and Hydraulic schematics.

Upright TM12 Specifications

General

Brand	Upright
Model	TM12
Category	Lifting Systems
Language	English
