Introduction

107098-002 TM12 - Operator Manual Page 3

NTRODUCTION

This manual covers the TM12 Aerial Work Platform. This manual must be stored on the machine at all

times.

Read, understand and follow all safety rules and operating instructions before attempting to operate the

machine.

ENERAL

ESCRIPTION

Figure 1:

TM12 Series

WARNING

DO NOT use the machine

if all guardrails

are not properly in place and secured with

all fasteners properly torqued

1. Platform

2. Entry Chain

3. Elevating Mast

4. Platform Controls

5. Manual Case

6. Electrical Box

7. Hydraulic Reservoir

8. Battery Tray

9. Emergency Down Valve Knob

10. Battery Charger

11. Charger Outlet Plug
