DS1093-520 6
Here follow a Summarize about the most Features:
1.2 OPENING THE BOX
Check that the packing and the contents are not visibly damaged. Contact the retailer immediately if parts are either
missing or damaged. Do not attempt to use the device in this case. Send the product back in its original packing if it is
damaged.
1.2.1 CONTENTS OF THE BOX
Hybrid DVR
Power unit
• INPUT ⇒ 100-240 Vac 50/60Hz 1.5 A max.
• OUTPUT ⇒ 12Vdc 2A
Quick Guide and Addendum
Mini CD containing Urmet software
Mouse
IR remote control, (included 2 batteries size AAA)
Cross LAN cable cat. 5
IMPORTANT NOTE
Accessories may be changed without prior notice.
Function Brief and Description
Real time
monitoring
Double video output with monitor, VGA virtual output port or HDMI Output; Support
URMET UVS Client Software and MP live surveillance and also support zoom in/out,
auto sequence and PIP display.
Record
H.264 video compression format; record quality/resolution/frame rate adjustable,
multiple record modes (Always, Scheduled, Manual, Alarm (if available), Motion
detection and remote record)
Record storage Support SATA large capacity HDD and save real-time record image to HDD.
Playback Support DVR single CH and multiple CH Search/Playback of recorded files.
Backup Support DVR backup via USB flash drive, removable drive, Recorder and network.
Motion
detection
Supports the motion detection function for recording on HDD each video channel
connected to the DVR.
Network
operation
Supports remote surveillance by authority users to increase system security.
Mouse
Operation
Supports Mouse operation for faster menu navigation.
PTZ Control Supports PTZ camera operations through RS-485, COAXITRON and UTC
