US Cutter LaserPoint - Finding the COM Port

- 18 -
Replacing a Worn Blade
First remove the blade carriage from the carriage arm,
Unscrew the cap of
the blade carriage
Press up on the
release button
located on the
bottom of the blade
carriage to raise the
blade and remove it.
Follow the remaining steps from “Installing a New Blade” above.
Loosen the locking knob on the
carriage arm.
Place Blade carriage (blade side
down) into the carriage arm.
Tighten the locking knob on the
carriage arm.
