Utax P-4530DN Service Manual

2LV/2L1/2L2/2MS/2MT
2-4-2
(2) Repetitive defects gauge
44.9 mm/1 3/4” Developer roller
36.8 mm/1
7/16” Registration roller
29.9 mm/1
3/16” Chager roller
94.2 mm/3
11/16” Drum/Press roller (60/50/45 ppm)
109.9 mm/4
5/16” Heat roller (60/50/45 ppm)
78.5 mm/3 1/16” Press roller (40 ppm)
84.8 mm/3 5/16” Heat roller (40 ppm)
61.2 mm/2 7/16” Transfer roller
First occurrence of defect
