Utax P-4530DN Service Manual

2LV/2L1/2L2/2MS/2MT-2
1-2-2
1-2-2 Unpacking and installation
Figure 1-2-2
Caution: Place the machine on a level surface.
Unpacking
9
1
3
4
7
12
10
8
5
6
13
2
11
1. Outer case
2. Inner case
3. Bottom pad R
4. Bottom pad L
5. Machine cover (740 × 700)
6. Machine
7. Upper pad R
8. Upper pad L
9. Top tray
10. Operation guide
11. Operation sheets Assy *1
12. Waste toner bottle
13. Power cord
*1: Except 240V model
