2LV/2L1/2L2/2MS/2MT
1-2-13
1-2-4
Install the memory card (SD card) (option)
Procedure
1.
Remove the main PWB assembly from
the machine. (See
Page 1-2-12)
2.
SD card is inserted in a SD
card slot.
Maximum memory cap
acity 32 GB.
3.
Remove the main PWB assmbly and
the cove
rs.
F
i
g
u
r
e 1-
2-
2
4
SD card
Main PWB assembly
SD card slot
37
39
