Utax P-4530DN Service Manual

2LV/2L1/2L2/2MS/2MT-1
1-4-24
1-4-3 Image formation problems
If the part causing the problem was not supplied, use the unit including the part for replacement.
(1) No image
appears (entirely
white).
(2) No image
appears (entirely
black).
(3) Image is too
light.
(4) The back-
ground is col-
ored.
(5) White streaks
are printed verti-
cally.
See page 1-4-25 See page 1-4-25 See page 1-4-26 See page 1-4-27 See page 1-4-27
(6) Black streaks
are printed verti-
cally.
(7) Streaks are
printed horizon-
tally.
(8) Spots are
printed.
(9) Image is
blurred.
(10)Paper is wrin-
kled.
See page 1-4-28 See page 1-4-28 See page 1-4-28 See page 1-4-29 See page 1-4-29
(11)Offset occurs. (12)Part of image is
missing.
(13)Fusing is loose. (14)Image is out of
focus.
(15)
Carrier leaking
occurs.
See page 1-4-29 See page 1-4-29 See page 1-4-30 See page 1-4-30 See page 1-4-30
