2LV/2L1/2L2/2MS/2MT
1-2-3
1. Remove two tapes.
2. Remove the protection sheet.
Figure 1-2-3
3. Remove four tapes.
Figure 1-2-4
Removing the tapes and pads
Protection sheet
Tape
Tape
Tape
Tape
Tape
Tape
