Utax P-4530DN Service Manual

2LV/2L1/2L2/2MS/2MT
1-2-11
8. Press the power switch and then check
the lighting up of ready indicator.
9. Installing the printer driver (refer to
operation guide).
Figure 1-2-21
1. Press the menu key.
2. Select [Device Common] using the cursor up/down keys.
3. Press the OK key.
4. Select [Language] using the cursor up/down keys.
5. Press the OK key.
6. Select the language to set using the cursor up/down keys.
7. Press the OK key.
1. Press the menu key.
2. Select [Report Print] using the cursor up/down keys.
3. Press the OK key.
4. Select [Status Page] using the cursor up/down keys.
5. Press the OK key.
6. Select the [YES] using the left select key.
7. [Accepted] is displayed and the page will be printed.
8. Press the menu key.
Power on
ON
ON
Ready indicator
Power switch
Setting the language
Printout the status page
Completion of the machine installation
