V2 CALYPSO User Manual

ENGLISH
12
TO CONNECT CALYPSO WITH CONTROL UNIT
 WARNING: always remember to connect the earth
according to current standards (EN 60335-1, EN 60204-1).
Avoid tension in the cable during open and close operations
.
EMERGENCY RELEASE
In case of a blackout, the gate can be operated
directly from the motor. Insert the key supplied
in the lock, perform 1/2 of a turn.
To restore the automation, simply rotate the key
in closed position and insert the provided plastic
cover onto the lock.

YELLOW - GREEN GND

BLUE (230V mod.)
WHITE (120V mod.)
COMMON

BLACK CLOSING

BROWN OPENING
