PARAMETER VALUE DESCRIPTION DEFAULT MEMO
St.rt
Activation inputs (START and START P.)
PD12 control unit is equipped with two activation inputs, whose operation
depends on the programmed operation modes (see chapter 4.7):
StAn
StAn
Standard mode
no
Start inputs from terminal board are disabled.
Radio inputs operate in standard mode
AP.Ch
Open/Close command
PrES
Manned operation
oroL
Timer mode
StoP
Stop Input
no
no
The input STOP is not available
ProS
The input STOP stops the gate: pressing the command START the gate
continues the motion
invE
The command STOP stops the gate: at the next START the gate starts
moving in the opposite direction
Foto
Exterior photocell input
This menu makes it possible to enable the exterior photocell input, i.e.
inactive during opening (see the section regarding installation).
CFCh
CFCh
Input enabled even at standstill gate too: the opening movement does not
start if photocell is interrupted
no
Input disabled (ignored by the control unit)
Ch
Input enabled for the closing phase only.
Warning: if you select this option, you must disable photocell test
Fot.i
Interior photocell input
This menu makes it possible to enable the interior photocell input, i.e.
active during opening and closing (see the section regarding installation).
no
no
Input disabled (ignored by the control unit)
AP.Ch
Input enabled
Ft.tE
Test of the photocells
Si
no - Si
In order to achieve a safer operation for the user, the unit performs a
photocells operational test, before a normal working cycle.
If no operational faults are found, the gate starts moving.
Otherwise, it will stand still and the flashing light will stay onfor 5 sec.
The whole test cycle lasts less than one second.
CoS1
Safety ribbon 1 input
This menu allows enabling the input for type 1 safety ribbon (fixed
ribbons)
no
no
Input disabled (ignored by the control unit)
AP
Input enabled during the opening and disabled during the closure
APCh
Input enabled in opening and closure
CoS2
Safety ribbon 2 input
This menu allows enabling the input for type 2 safety ribbon, that is to say
mobile ribbons
no
no
Input disabled (ignored by the control unit)
Ch
Input enabled during closure and disabled during opening
APCh
Input enabled in opening and closure
