5.4 Start / stop setup (Control panel: Menu PAR -> P2)
5.5 Frequency references (Control panel: Menu PAR -> P3)
NOTE! These parameters are shown, when P17.2 = 0.
Code Parameter Min Max Unit Default ID Note
P2.1
Remote Control
Place Selection
0
1 0 172
0 = I / O terminals
1 = Fieldbus
Start function
0
1 0 505
0 = Ramp
1 = Flying start
Stop function
0
1 0 506
0 = Coasting
1 = Ramp
P2.4
I / O Start / Stop
logic
0 3 2 300
I / O control I / O control
signal 1 signal 2
0 Forward Reverse
1 Fwd (edge) I nverte d Sto p
2 Fwd (edge) Rev (edge)
3 Start
Reverse
P2.5 Local / Remote 0 1 0 211
0 = Remote control
1 = Local control
P2.6
Keypad control
direction
0 1 0 123
0 = Forward
1 = Reverse
Keypad button
lock
0 1 0 15520
0 = unlock all keypad button
1 = Lock/Rem button locked
Table 5.4: Start / stop setup
Code Parameter Min Max Unit Default ID Note
Min frequency 0,00 P3.2 Hz 0,00 101
Minimum allowed
frequency reference
Max frequency P3.1 320,00 Hz
50,00 /
60,00
102
Maximum allowed
frequency reference
P3.3
Remote Control
Place frequency
reference
selection
16 4117
1 = Preset Speed 0
2 = Keypad
3 = Fieldbus
4 = AI1
5 = AI2
6 = PI
P3.4 Preset speed 0 P3.1 P3.2 Hz 5,00 180 Activated by digital inputs
P3.5 Preset speed 1 P3.1 P3.2 Hz 10,00 105 Activated by digital inputs
P3.6 Preset speed 2 P3.1 P3.2 Hz 15,00 106 Activated by digital inputs
P3.7 Preset speed 3 P3.1 P3.2 Hz 20,00 126 Activated by digital inputs
P3.8 Preset speed 4 P3.1 P3.2 Hz 25,00 127 Activated by digital inputs
P3.9 Preset speed 5 P3.1 P3.2 Hz 30,00 128 Activated by digital inputs
P3.10 Preset speed 6 P3.1 P3.2 Hz 40,00 129 Activated by digital inputs
P3.11 Preset speed 7 P3.1 P3.2 Hz 50,00 130 Activated by digital inputs
Table 5.5: Frequency references
