vacon • 6 Modbus - general info
Local contacts: http://drives.danfoss.com/danfoss-drives/local-contacts/
Figure 2.Principal example diagram of Modbus
2.1 Restrictions
When a fieldbus option board or an OPTBH option board has been installed, Modbus is not working.
Ethernet
Modbus TCP
Modbus RTU
Modbus
RTU
master
Switch
11781_uk
