Vacon NXP series Quick Guide

4
COOLING / REFROIDISSEMENT / KÜHLUNG / RAFFREDDAMENTO /
REFRIGERACIÓN / REFRIGERAÇÃO / 冷却
The minimum clearance around the drive
Dégagement minimal autour du convertisseur
Mindestabstand um den Umrichter herum
Distanza minima intorno all’inverter
La separación mínima alrededor del convertidor
Espaço livre mínimo ao redor do conversor
变频器周围的最小间隙
EN
FR
DE
IT
ES
PT-
BR
ZH
Drive type
A B C D
mm (in)
0003 2-0012
20003 5-0012 5
20
(0.79)
20
(0.79)
100
(3.94)
50
(1.97)
0017 2-0031
20016 5-0031 5
20
(0.79)
20
(0.79)
120
(4.72)
60
(2.36)
0048 2-0061
20038 5-0061
50004 6-0034 6
30
(1.18)
20
(0.79)
160
(6.30)
80
(3.15)
0075 2-0114
20072 5-0105
50041 6-0052 6
80
(3.15)
80
(3.15)
300
(11.81)
100
(3.94)
0140 2-0205
20140 5-0205
50062 6-0100 6
80
(3.15)
80
(3.15)
300
(11.81)
200
(7.87)
0261 2-0300
20261 5-0300
50125 6-0208 6
50
(1.97)
80
(3.15)
400
(15.75)
250
(9.84)
A
A
2
D
A
A
2
B B
C

Vacon NXP series Specifications

General

Communication interfaces	RS-485, Ethernet
Storage temperature range	-40°C to +70°C
Dimensions	Varies by model
Weight	Varies by model
Product series	NXP
Voltage range	200 V to 690 V
Input voltage range	200 V to 690 V
Frequency range	0 Hz to 500 Hz
Control method	Vector control
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature, short circuit
Enclosure classes	IP21, IP54
Braking chopper	Built-in or external
EMC filter	Built-in or external
Communication protocols	Modbus, Profibus, CANopen, Ethernet
Operating temperature range	-10°C to +50°C
Humidity range	5% to 95% (non-condensing)
Cooling method	Air-cooled or liquid-cooled
