Vaillant VR 34 - Assembly; Interface Assembly

8 Installation instructions - Interface 0-10 V VR 34 0020017083_02
Fig. 4.1 Connecting the bus cable to the connection
terminal
1
3
2
Fig. 4.2 Installing the interface PCB
F
I
4
2V
4
3
Fig. 4.3 Cable duct
• Secure the 0-10 V interface with the en-
closed cable clamp (4).
4 Assembly
