Section 10 - Part Number List MM147 - D4 Hot Melt Unit
136
Relief Valve Assembly (594xx189)
Refer also to Appendix C - Instruction Sheets for Option Kits: 999XD774-197
Unit Description Part # QTY
1 707XX897 VALVE ASSY,PRESSURE RELIEF 1
2 797XX079 HEX NIPPLE M-M 1/8 1
3 411XX118 VALVE ASSY, 3-WAY W/M12 24V 1
4 799XX582 CONNECTOR,MALE: 8MM X 1/8 NPT 2
5 755XX575 TUBING,NYLON,8MM O.D. 360
6 797XX395 FITTING, MALE: 5/16I X 1/4NPT 4
7 797XX019 STREET TEE F-F-M 1/4 1
8 594XX033 FILTER REGULATOR ASSY. 1
9 582XX300 BRACKET-REGULATOR 1
10 594XX004 AIR REGULATOR M750LPG 1
11 580XX861 BRACKET 1
12 999XD774-197 ILLUST. DWG.: UNIFLOW REL. VA 1
