MM147 - D4 Hot Melt Unit Section 5 - Setup
91
D Series Variable Frequency Drive Configuration (If Equipped)
1. Press ‘DSP’ to display ‘F’ number; use arrow keys to reach function to change.
2. Press ‘Data Ent’ to display current value, use arrow keys to change value.
3. Press ‘Data Ent’ to save new function value.
4. Press ‘DSP’ key to exit or arrow keys to go to the next function number.
Valco Setting Factory Default Function Range
AI1T Voltage 5V Configuration of AI1 5V, Voltage, or Current
L01 Drv. Running NO L01 Assignment Multiple
BFR 60 50 Std. Motor Frequency 50HZ or 60HZ
DEC 5 3 Deceleration Ramp Time 0-999.9 SEC.
LSP 10 0 Low Speed Frequency 0-63.2 HZ
HSP 63.2 60 High Speed Frequency 10-72 HZ
