10 Wiring Information
Wiring colours are correct at the time the manual was printed. However, it is advised that continuity checks
are performed prior to all terminations.
10.1 Tide (Pressure)
END 1:
Pressure Sensor
END 2: 6Way Connector UTS6JC10E6P
PRESSURE
CONNECTOR
PIN
Druck PDCR1830
6 Way Modified UTS -
UTS6JC10E6P
A
V+
B
GND
C
SIG+
D
SIG-
E
N/C
F
Screen
10.2 Tide (Radar)
END 1:
0745518 PCB
Into Radar
Junction Box
END 2:
0745518 PCB
Out of Radar Junction
Box
END 3:
UTS6JC10E7S
TideMaster
END 4:
D - Type
(for setup)
FUNCTION
PIN
BOARD
PIN
PIN
PIN
1
POWER_GND
2
POWER_IN
3
RS232_OUT OF
RADAR
4
RS232_IN TO RADAR
5
RS232_GND
6
SCREEN
J3
6Way
Terminal
block
(Stripped &
twisted end)
1
B
POWER_GND
2
A
POWER_IN
3
D
RS232_OUT OF
RADAR
4
C
RS232_IN TO RADAR
5
E
RS232_GND
6
E
SCREEN
2
RS232_OUT OF
RADAR
3
RS232_IN TO RADAR
1,5,6,8,9
RS232_GND
SHELL
SCREEN
