10.3 WindSONIC
END 1: GILL Sensor
END 2: 6Way UTS -
UTS6JC10E6P
FUNCTION
CONNECTOR
PIN
CONNECTOR
PIN
Windsonic 9 way
connector as supplied
with Windsonic Sensor
3
6 WAY UTS -
UTS6JC10E6P
A
V+
2
B
GND
7
C
RS232 Out to Gill
5
D
RS232 In from Gill
1
E
Gill 232 Gnd
F
Screen
10.4 METPAK II
END 1:
GILL MetPak II
END 2:
6Way UTS -UTS6JC10E6P
FUNCTION
CONNECTOR
PIN
CONNECTOR
PIN
J5
8 way Push fit Block
Pin 1 is nearest edge of
board adjacent to earth
post.
8
6 WAY UTS -
UTS6JC10E6P
A
V+ Supply to Gill
7
B
GND Supply to Gill
4
C
RS232 Out to Gill
3
D
RS232 In from Gill
2
E
Gill 232 Gnd
F
Screen
10.5 MaxiMet
Available from firmware version 0741705B9
END 1:
GILL MaxiMet Sensor
END 2:
6Way UTS -UTS6JC10E6P
FUNCTION
CONNECTOR
PIN
CONNECTOR
PIN
MaxiMet 9 way connector
as supplied with MaxiMet
Sensor
2
6 WAY UTS -
UTS6JC10E6P
A
V+ Supply to Gill
3
B
GND Supply to Gill
7
C
RS232 Out to Gill
5
D
RS232 In from Gill
1
E
Gill 232 Gnd
F
Screen
Only to be used with Gill MaxiMet sensor
