1.3 Mounting Template
1.4 Specifications
Pressure Transducer
Type:
Vented strain gauge, with stainless steel mounting bracket.
Range:
Standard 10dBar (approx 10m), with 20m cable.
Other pressure ranges and cable lengths are available.
Accuracy:
±0.1% Full Scale.
Calibration:
Held within logging unit.
Dimensions:
18mm diameter x 80mm.
VRS-20 Radar Level Sensor
Type:
Pulsed K-band radar level sensor
Minimum Range:
0.8 m
Maximum Range:
20 m
Beam Angle:
±6°
Frequency:
25 GHz
Accuracy:
±10 mm
Precision:
1 mm
Dimensions
Length:
255mm
Width:
130mm
Height:
130mm (75mm without mount)
Weight:
~2 kg
