Rear Panel Functions
3-6 Force 2 User’s Guide
Rear Panel Functions
On/Off Switch – Press the toggle upward to turn power on and down to shut
power off.
The Force 2 generator uses a universal type power entry module but is not
voltage selectable. Line fuse replacement is the following:
250V 8A 110-120V generators (-2 PCH)
250V 6.3A 220-240V generators (-8 PCH)
Bipolar Footswitch Receptacle – This three-pin receptacle accepts a single-
pedal bipolar footswitch connector.
Monopolar Footswitch Receptacle – This four-pin receptacle accepts a two-
pedal monopolar footswitch connector.
Equipotential Lug – This lug may be connected to earth ground with an
equipotential grounding cable.
Audio Volume Control – The volume of the cut, coag, and bipolar mode
indicator tones produced when the generator is activated may be adjusted
with this control. The volume of the audio alarm is not adjustable.
