CONTENTS
Section Heading Page
INSTALLER GUIDE 4 - 39
OWNER GUIDE 40 - 51
1. SAFETY 7
2. APPLIANCE DATA AND EFFICIENCY 8
2.1 General information. 8
2.2 Efficiency. 9
3. LIST OF AVAILABLE KITS 9
4. APPLIANCE AND RECESS DIMENSIONS 12
5. GENERAL INSTALLATION REQUIREMENTS 12
5.1 Regulations, Standards and Law. 12
5.1.1 Considerations for timber framed buildings. 12
5.2 Ventilation requirements. 13
5.3 Fireguard requirements. 13
5.4 Room considerations. 13
5.5 Fireplace preparation. 13
5.6 The surround. 13
5.7 Hearth / plinth requirements. 14
5.8 Fireplace clearances. 15
5.9 Installation options. 16
5.10 Terminal guard and terminal clearances. 16
6. UNPACKING AND PRELIMINARY CHECKS 19
6.1 Unpacking. 19
6.2 Appliance disassembly. 19
6.3 Preliminary checks. 20
7. GAS SUPPLY CONNECTION 20
8. WALL PREPARATION 21
8.1 Select appliance position. 21
8.2 Constructing a recessed opening. 21
8.3 Combustible wall materials. 22
8.4 Cutting the flue hole for brick, stone etc. building. 23
8.5 Cutting the flue hole in timber frame buildings. 24
8.6 Prepare appliance fixing holes. 25
INSTALLER GUIDE
Page 5
© Baxi Heating U.K. Limited 2010.
