© Baxi Heating U.K. Limited 2010.

Table of Contents

Default Chapter5
- Table of Contents5
Installer Guide6
1 Safety7
2 Appliance Data and Efficiency8
- General Information8
- Efficiency9
3 List of Available Kits9
4 Appliance and Recess Dimensions10
5 General Installation Requirements12
- Regulations, Standards and Law12
- Considerations for Timber Framed Buildings12
- Ventilation Requirements13
- Fireguard Requirements13
- Room Considerations13
- Fireplace Preparation13
- The Surround13
- Hearth / Plinth Requirements14
- Fireplace Clearances15
- Installation Options16
- Terminal Guard and Terminal Clearances16
6 Unpacking and Preliminary Checks19
- Unpacking19
- Appliance Disassembly19
- Preliminary Checks20
7 Gas Supply Connection20
8 Wall Preparation21
- Select Appliance Position21
- Constructing a Recessed Opening21
- Combustible Wall Materials22
- Cutting the Flue Hole for Brick, Stone Etc. Building23
- Cutting the Flue Hole in Timber Frame Buildings24
- Prepare Appliance Fixing Holes25
9 Flue and Terminal Installation25
- Cutting Flue to Size25
- Fitting to Wall27
- Fitting the Terminal Guard28
10 Gas Connection28
11 Ceramic Coals Installation29
12 Ceramic Pebbles Installation31
13 Window Fitting33
14 Full Operating Checks33
- Check for Leaks33
- Check Control Operation33
- Checking Inlet Pressure34
15 Fascia Fitting35
16 Final Review36
17 Servicing & Parts Replacement37
- To Remove Fascia37
- To Remove Window Unit38
- To Remove the Ceramic Fuel Effect and Rear Wall38
- To Remove the Complete Burner Module38
- To Remove the Burner from the Burner Module38
- To Remove the Injector39
- To Remove the Pilot Unit39
- To Remove the Gas Valve39
Owner Guide40
- Owner Guide51
