Valor G3.5 Installation Manual

41
Appendix C—Spare Parts
Description Part No.
1 VDRT slider assembly 4006540
2 Exhaust plate gasket 4001662
3 Shroud (2) 4003295
4 Burner cover platform 4007921
5 Log support bracket 4008289
6Side cover 4002806
7Valve access plate 4002510
8 Access plate gasket 4002664
9 Window assembly 4004409
10
Explosion lever assembly (right
hand)
4003680
11 Explosion level assembly (left hand) 4003681
12 Hot glass warning plate 4003093
13 Battery holder cable (1500 mm) 4006552
14 Battery holder 4008039
15 Handset GV60 MAX 4002251
16 Handset wall holder 9000008
17 GV60 valve repair kit (not included) 4004544
18
Burner module assembly
(natural gas)
4007922
Burner module assembly
(propane gas)
4007923
19 Pilot shield 4003890AH
20
Pilot assembly (natural gas) 4006019
Pilot assembly (propane gas) 4006020
21 Plug pilot 4000726
22
Pilot assy injector #51 (natural
gas)
4000727
Pilot assy injector #30 (propane
gas)
4000728
23 Thermocouple 4004801
24
Pilot injector #51 (natural gas) 4000735
Pilot injector #30 (propane gas) 4000736
25 Pilot tube 4005046
26 Pilot hood 2-fl ame 4000730
27 Burner 4007354
28 Pilot bracket 4007142
29 Platform stand 4007799
Description Part No.
30 Burner mount (2) 4007140
31 Platform fi xing bracket 4008079
32 Flex pipe assembly with valve 4002475
33 Anti-fl ashback shield 4007629
34 Air shutter 4007136
35 Spring tension washer 4007460
36 Steel fl at washer 4007461
37
Injector elbow #750 (natural gas) 4000738
Injector elbow 92-260 (propane) 9730007
38 Gas supply tube assembly 4007875
39 Thermocouple interruptor block 4001037
40
GV60 valve assembly (natural gas) 4008333S
GV60 valve assembly
(propane gas)
4003163S
41 Module side plate top gasket 4003238
42 Module side plate side gasket (2) 4002404
43 Module side plate bottom gasket 4003237
44 Receiver (MAX version) 4002422
45 Single pipe sealing plate 4003236
46 Thermocouple pilot sealing plate 4007887
47 Wiring harness GV60 4001187
48 Ignition cable 4001039
49 Ignition cable sleeve (530 mm) 4002244
50 Interruptor cable (red) 4001035
51 Switch with cable 4001036
52 Birch Log Kit 700BLK
Birch Log G1 4008159
Birch Log G2 4008160
Birch Log G3 4008161
Birch Log G4 4008162
Birch Log G5 4008163
Birch Log G6 4008164
Birch Log H7 4007469
Birch Log H9 4007471
Birch Log H10 4007472
Birch Log H11 4007473
53 Embers (2 cup bag) 4008304
