37
Appendix B—Remote Control Operation
Set temp 74ŐF Set temp 40ŐFSet temp 74ŐF
Set temp 40ŐF
Timer Programming Example (default temperatures shown)
Setting P2 high and low temperature times.
Repeat same steps as Setting P1.
When all settings are complete, press
to save them.
6:00 am
P1
high temp
8:00 am
P1
low temp
4:00 pm
P2
high temp
10:00 pm
P2
low temp
6:00 am
P1
high temp
Automatic Turn Down
8-Hour no Motor Movement
The valve will turn to pilot ȵ ame if there is no motor
movement for an 8-hour period.
Automatic Shut-O
Low Batteries Receiver. With low battery power
in the battery holder the system shuts o the ȴ re
completely. This does not apply when the power supply
is interrupted.
On-Demand Pilot (7 Day Shut-O ). This green feature
eliminates gas energy consumption during extended
appliance inactivity. When the appliance is inactive for
an extended period of time the system automatically
extinguishes the pilot. This feature helps the consumer
realize cost beneȴ ts by automatically eliminating
energy consumption during non-heating months and
limited use.
The programmed length of inactivity to activate the
system is speciȴ ed by the appliance manufacturer and
cannot be altered in the ȴ eld.
Low Battery Indication
Handset: The battery icon will show when the bat-
tery needs to be replaced. Replace with one 9 V alkaline
battery.
Battery holder: Frequent ‘beeps’ for 3 seconds when
the valve motor turns indicate the batteries need to be
replaced in battery holder. Replace with four 1.5 V alka-
line batteries.
Handset / Receiver Match
The remote control handset and receiver are
programmed to function together. In case of a
replacement of the handset or the receiver, you will
need to reset the receiver to allow them to function
together. Contact your dealer for details.
ɄCaution
DO NOT USE a screwdriver or other metallic
object to remove batteries from holder. This
could cause a short-circuit.
