Valtra T214 User Manual

1
2
GUID-6EEF62BA-2A85-47C4-BD81-D1374F72BAD5
1. Lifting push button
2. Lowering push button
3.12.1 Diagnostic light
When the tractor power is turned on, the diagnostic light is lit for a moment, goes
out, and is lit again. The lit diagnostic light indicates that the linkage has not been
activated.
1
GUID-7A638FAD-60B6-4705-AA27-FD5BF18555AB
1. Diagnostic light
IMPORTANT: If the diagnostic light is flashing and a service code is displayed,
there is failure in the system. Contact an authorised Valtra workshop
3. Operation
- 168 -

Valtra T214 Specifications

General

Transmission	Powershift
Max Speed	50 km/h
Engine Type	6-cylinder diesel
Displacement	7.4 liters
Engine	AGCO Power
Rear Lift Capacity	9500 kg
Lift Capacity	9, 500 kg
Wheelbase	2.995 m
Hydraulic System	Load-sensing
Tire Options	Multiple options available
