3.19.1 ISOBUS terminal connector
The ISOBUS terminal connector is part of the ISOBUS implement control system
(extra equipment). The connector is used to connect the terminal to the ISOBUS
system.
The connector includes both an ISOBUS data bus and a power supply.
3.19.2 ISOBUS implement connector
The ISOBUS implement connector is part of the ISOBUS implement control
system (extra equipment). The connector connects an ISOBUS compatible
implement to the ISOBUS system.
3.19.3 Bus extension connectors
Bus extension connectors are part of the ISOBUS implement control system
(extra equipment). Normally the bus extension connectors are connected
together. They can also be used to connect additional ISOBUS devices to
ISOBUS (for example, ISOBUS GPS).
NOTE: If the bus extension connectors are disconnected, the ISOBUS implement
bus is broken and the system does not function properly. When connecting
additional ISOBUS devices, check that the bus stays intact (the bus extension
connectors are connected).
The connector is located under the side panel.
3.19.4 ISOBUS terminal
The C1000 ISOBUS Terminal (extra equipment) is used to control ISOBUS
implements and the auto-steering system.
The terminal fulfils the basic UT (Universal Terminal) requirements. For more
information about the terminal, refer to the C1000 ISOBUS Terminal user
manual.
There is also an in-build task controller in the terminal. Refer to the task controller
user manual for more information.
The terminal has a connector also for a camera (extra equipment).
3.20 Auto-Guide Readiness
Auto-Guide Readiness makes it possible to install Auto-Guide 3000 steering
system to the tractor. Auto-Guide 3000 is based on global navigation satellite
system (GNSS) and it is capable of steering the tractor automatically. Auto-Guide
Readiness is extra equipment. Refer to the Auto-Guide 3000 user manual for
more information.
Auto-Guide Readiness consists of the following equipment:
3. Operation
- 223 -
