Valtra T214 User Manual

• Set the steering wheel rake.
• Press the locking pedal down.
• Adjust the steering wheel rake to the desired position.
• Release the pedal.
3.2.4 Adjusting standard mirrors
You can adjust the position of the standard mirrors manually.
1
GUID-84D4C889-6DC1-407F-86DA-FFD8196A71C1
1. Locking device of the mirror support
1. Loosen the locking device of the mirror support.
2. Adjust the mirror position.
3. Tighten the locking device.
3.2.5 Adjusting optional mirrors
You can adjust the position of the optional mirrors electrically.
1
L R
2
GUID-7737973C-BFC2-4F4C-971A-C6793957F5FC
1. Mirror adjustment
2. Telescopic mirror adjustment
3. Operation
- 68 -

Valtra T214 Specifications

General

Transmission	Powershift
Max Speed	50 km/h
Engine Type	6-cylinder diesel
Displacement	7.4 liters
Engine	AGCO Power
Rear Lift Capacity	9500 kg
Lift Capacity	9, 500 kg
Wheelbase	2.995 m
Hydraulic System	Load-sensing
Tire Options	Multiple options available
