GUID-9BAD42F5-6A0F-4B12-8234-9190C88A5F49
1. Connector X130
When the light switch is in the headlight position, the upper high beams
(optional) operate as an additional high beams when the connector X130
(black wire 185) is connected together. If the high beams of the upper
headlights glare, disconnect the X130 connector to turn them off.
When the light switch is in the upper headlight position, high beams operate
only on the upper headlights.
• To use the headlight flasher, pull the multifunction lever towards yourself a bit
when the dipped–beams are on.
3.4.2 Using the follow-me-home functionality
In the follow-me-home functionality, the front waist working lights (optional) are
still on even if the power is turned to the (OFF) position and you exit the cab.
• To use the follow-me-home functionality, turn the ignition key to the
(OFF) position and open the door before the main power turns off.
The follow-me-home functionality activates automatically at the same time as
the cab lights. The follow-me-home lights turn off when the cab lights or the
main power turn off.
NOTE: The main power is not turned off if the hazard warning flasher or the
parking lights are turned on. If the door is left open in such a situation, the
cab lights and the follow-me-home lights are turned off after about 10
minutes.
3.4.3 Using the working lights
The parking lights or the headlights must be switched on before you can use the
light panel. If the parking lights or the headlights are not switched on and you try
to use the light panel, the symbol on the light panel on/off button blinks few times.
3. Operation
- 83 -
