Valtra T214 User Manual

3.2.16 Main power
The main power is controlled by the ignition switch.
The main power is automatically turned on when you turn the ignition key to other
than the (OFF) position. When you turn the ignition key to the (OFF)
position, the main power is turned off after a delay. During this delay, data is
saved, the system performs a controlled shutdown and the urea system lines are
emptied. The light in the light switch is lit until the main power is switched off.
The main power is not switched off automatically in the following situations:
• the parking lights are on
• the hazard warning flasher is on
• the control electronics request for additional time (maximum of one hour), for
example, the Auto-Guide system
3.2.17 Using the main power emergency button
In case of an emergency, all power can be switched off immediately without a
delay by pressing the main power emergency button when the ignition key is
removed. In normal use, the main power is switched off after a delay when you
turn the ignition key to the (OFF) position, and there is no need to use the
main power emergency button.
1
2
3
GUID-662324B9-8FB4-4FF7-BEDB-61435F936ACF
1. Main power emergency button
2. Main power on (green light)
3. Main power off (red light)
The main power emergency button has a green and a red LED light to indicate its
status.
3. Operation
- 76 -

Valtra T214 Specifications

General

Transmission	Powershift
Max Speed	50 km/h
Engine Type	6-cylinder diesel
Displacement	7.4 liters
Engine	AGCO Power
Rear Lift Capacity	9500 kg
Lift Capacity	9, 500 kg
Wheelbase	2.995 m
Hydraulic System	Load-sensing
Tire Options	Multiple options available
