Valtra T214 User Manual

Maximum input torque (Nm) 1170
Nominal input torque (Nm) 925
6.10.6.1 Front power take-off ratio
Front power take-off (PTO) ratio
1 000 rpm at engine speed 1 900 rpm
6.10.6.2 Front power take-off shafts
Splines Standard Shaft diameter (mm)
6 ISO 500 35
6.11 Brake system
Operation • Hydraulically controlled multi-disc type brakes
with wet discs
• Boosted with low-pressure hydraulics
• Two brake cylinders
• No separate brake fluid
• Pressure accumulator to ensure the pressure
• Oil spray cooling of the friction disc elements
when necessary
Number of brake friction discs 5 pcs/side
Friction disc diameter 242.5 mm
Brake friction area
4 272 cm
2
/organic
Brake pedal free travel 35-45 mm
Parking brake
Operation • Electro-hydraulically controlled with power shuttle
lever
• Driving brakes engaging with spring, disengaging
with hydraulic pressure
Hydraulic trailer brake valve (extra equipment)
Operation • Operated with the hydraulic pump for
transmission and steering, controlled by the
braking pressure
• Trailer brake connection to the tractor with quick
coupling
Trailer air pressure brakes (extra equipment)
Operation • Operated with air pressure system, controlled by
the braking pressure
• Trailer brake connection to the tractor with quick
coupling
6.12 Steering system
Type
• Hydrostatic
• Oil supply from the transmission hydraulic pump
via the priority valve
• Adjustable, telescopic steering column
• Central frame, one double-action steering
cylinder
Maximum working pressure
18.5 MPa (185 bar)
Shock valve opening pressure 25 MPa (250 bar)
Table continued on next page
6. Technical specifications
- 393 -

Valtra T214 Specifications

General

Transmission	Powershift
Max Speed	50 km/h
Engine Type	6-cylinder diesel
Displacement	7.4 liters
Engine	AGCO Power
Rear Lift Capacity	9500 kg
Lift Capacity	9, 500 kg
Wheelbase	2.995 m
Hydraulic System	Load-sensing
Tire Options	Multiple options available
