Valtra T214 User Manual

3.21.6 Agricultural drawbar
The agricultural drawbar (optional) is used without the pick-up hitch.
1
GUID-7C0D87A3-6EED-45AA-8870-A33EC5DDD993
1. Agricultural drawbar
The agricultural drawbar is used for towing implements where only part of the
implement weight is on the drawbar, for example balers. See the technical
specifications in this manual for the maximum weight of the drawbar implement.
Agricultural drawbar:
• Adjustable to three different distances from the power take-off (PTO) shaft.
• In all positions, the drawbar can also be adjusted ± 21° to either side.
3. Operation
- 237 -

Valtra T214 Specifications

General

Transmission	Powershift
Max Speed	50 km/h
Engine Type	6-cylinder diesel
Displacement	7.4 liters
Engine	AGCO Power
Rear Lift Capacity	9500 kg
Lift Capacity	9, 500 kg
Wheelbase	2.995 m
Hydraulic System	Load-sensing
Tire Options	Multiple options available
