• Start the rear PTO by pressing the switch down and pulling it backward.
The indicator light on the proline instrument panel is lit.
AUTO
1
GUID-1F3C8457-93B5-4937-B524-A362B42389C4
1. Switch for rear PTO
• To start the rear PTO with the rear PTO on/off push button (optional) on the
mudguard, press the button continuously for at least 3 seconds.
The PTO starting begins after 0.5 seconds. If the pressing is interrupted
during these 3 seconds, the PTO stops.
ON/OFF
1
GUID-9C52E8CD-1973-4193-87D3-0FB5A42ECF73
1. Rear PTO on/off push button
3. Operation
- 209 -

Valtra T214 Specifications

General

Transmission	Powershift
Max Speed	50 km/h
Engine Type	6-cylinder diesel
Displacement	7.4 liters
Engine	AGCO Power
Rear Lift Capacity	9500 kg
Lift Capacity	9, 500 kg
Wheelbase	2.995 m
Hydraulic System	Load-sensing
Tire Options	Multiple options available
