2. If possible, tow the tractor in the same vertical angle in which the tractor you
want to tow is.
CAUTION: If you tow the tractor horizontally while the tractor is on
a slope, you can cause damage to the tractor.
3. Prepare the transmission for towing.
AUTO
1
GUID-0FB02081-7FE4-4AD6-9133-5607A86F4EF6
1. Speed range selection - button
Engage the parking brake.
Change to speed range LA.
Press down the speed range selection - button for a minimum of 3
seconds.
Setting the speed range to neutral is possible only if the driving speed is
below 1 km/h.
Transmission sets to neutral. The symbol for speed range goes out of
view from the A pillar display.
If you cannot change to neutral, try to change to the D range.
If you cannot change to the D range, follow the towing speeds below.
Release the parking brake.
If you are on a slope, push and hold down the brake pedals to prevent
the tractor from moving. Release the brake pedals when you are
prepared to start the towing.
4. Tow the tractor.
The maximum allowed towing speeds are:
Speed range A: 3 km/h
Speed range B: 6 km/h
Speed range C: 8 km/h
Speed range D: 10 km/h
Transmission in neutral: 10 km/h
Do not tow the tractor alone.
Make sure that someone operates the steering and the brakes in the
tractor you tow.
5. Troubleshooting
- 378 -
