WRM-10P/WRM-40 OPERATING INSTRUCTIONS
6.4 SETUP Menu:
This menu is displayed by selecting key #2
(SETUP) on the Start-Up menu.
a. Select key 1 to 4. When key #4 (NEXT
PAGE) is selected, more choices for setup
are shown.
6.4.1 Transformer Data Entries:
The operator can enter transformer test data
using the following procedures.
OPERATOR’S NOTE
Test identification data are entered
with the WRM-10P/40 keypad. The
keypad has 10 keys that are alpha-
numerically marked, like pushbuttons
on a telephone. Keys are pressed for
each character position (marked by the
cursor) in the identification area. For:
example, consider the key marked 2 A
B C. The first press of the key selects
the number “2,” pressing the key a
second time selects the letter “A,”
pressing the key a third time selects the
letter “B”, and pressing the key a
fourth time selects the letter “C.”
Further pressing of the key returns to
the number selection; the cycle repeats
as the key continues to be pressed. The
characters selected are entered at the
position of the cursor. Pressing the up
key (?) advances the cursor by one
space while pressing the down key (?)
moves the cursor back one space. If a
character is erroneously entered, select
the new key to get the desired entry.
a. Press key #2 from Start-Up menu then
press key #1 to select transformer data entry.
The first identification (ID) display is the
COMPANY screen, which is shown below:
b. Enter the characters of the utility
company’s name. When this is done, press
the ENTER key and go to the next step. The
STATION screen will then be displayed:
c. Enter characters for naming the station
where the transformer to be tested is located.
When all the characters are selected
(identifying the station), press the ENTER
key and go to the next step. The CIRCUIT
screen display:
d. Enter all characters needed to identify the
circuit name, then press the ENTER key and
go to the next step. The manufacturer screen
will display next.
2. REVIEW RECORD
3. RESTORE RECORD
4. NEXT PAGE
2. SET TIME
3. VOLTAGE REG. TEST
