WRM-10P/WRM-40 OPERATING INSTRUCTIONS
d. Press key # 1 if you know the record
number. Press key #2 if the user prefers to
scroll through the WRM-10P/40 directory
(see step f).
The above display prompts the operator to
enter the record number.
e. Enter Record number then press the
ENTER key. The next display will appear:
The above display confirms to the operator
that the selected record has been restored.
Continue on to step i.
f. Use ? and ? keys to scroll through the
WRM-10P/40 directory.
g. Press ? key to show the first record
header in memory.
h. Press ENTER key to recall the record. A
confirming record is shown in step e.
i. When the restoration is confirmed, press
the ENTER key to select the viewing option
as shown below.
j. If the user wants to scroll through the test
record, press key #1 and continue from step
6.4.3.b.
k. Press key # 2 to produce a test record
print out on the thermal printer. See Figure
8.0 or Figure 9.0 for a typical test record
printout.
6.4.3 Review a Test Record
This procedure describes steps to review a
test record residing in the WRM-10P/40?
working memory. The user can view the
record on the LCD screen or from a thermal
printout.
NOTE
To review a test record stored in Flash
EEPROM, the user must first restore the
test record from Flash EEPROM to
working memory (see paragraph 6.4.2).
a. These procedural steps begin by pressing
key #2 (SETUP) on the Start-Up menu. The
display below is now shown on the WRM-
10P/40 LCD:
NUMBER:
1. SCROLL TEST RECORD
2. PRINT TEST RECORD
“UP” TO SCROLL FWD
“DWN” TO SCROLL RSV
345KV NORTH
ABB
2. REVIEW RECORD
3. RESTORE RECORD
4. NEXT PAGE
