WRM-10P/WRM-40 OPERATING INSTRUCTIONS
24
e. Enter all characters needed to identify the
manufacturer of the transformer being
tested, then press yhe ENTER key and go to
the next step. The MODEL screen displays:
f. Enter the characters of the transformers
model number, then press the ENTER key
and go to the next step. The SERIAL
NUMBER screen displays:
i. Enter the alpha-numeric characters needed
to identify the serial number, then press
ENTER key and go to the next step. The
KVA RATING screen displays.
j. Enter the numbers to identify the KVA
rating for the transformer being tested, then
press the ENTER key and go to the next
step. The OPERATOR screen displays:
k. Enter the characters needed to identify the
operator who is performing the tests. This
completes entries for the transformer
identification data. Press the ENTER key to
complete the task. The program will return
to the Start-Up menu.
6.4.2 Restore a Test Record
This procedure allows the user to restore a
test record from the WRM-10P/40s Flash
EEPROM to working memory. The user can
then review the test record using the
REVIEW RECORD command (6.4.3) or
print the test results on the thermal printer.
a. These procedural steps begin by pressing
key #2 (SETUP) on the Start-Up menu. The
display below is now shown on the WRM-
10P/40 LCD:
b. Press key # 3 (RESTORE RECORD),
which shows a menu for three main
procedures, as displayed below:
c. Press key # 1 (RESTORE RECORD) to
begin the procedure. The next display
appears:
MODEL:
SERIAL NUMBER:
KVA RATI
NG:
OPERATOR:
1. ENTER XFMR ID
2. REVIEW RECORD
3. RESTORE RECORD
4. NEXT PAGE
1. RESTO
RE RECORD
2. DIRECTORY
3. ERASE RECORDS
4. NEXT PAGE
RESTORE RECORD
1. ENTER RECORD NUMBER
2. SCROLL TO SELECT
