BDR-720 Adela PRO
3.14 ATTACHED ILLUSTRATIONS
The attached illustrations are common for all language versions. They can be found at the end of this manual in Chapter 5, page 75.
Table 41
, page 55 , features the sign label and figure translations.
Fig. 1: Main Machine Components Fig. 2: Handlebars height and horizontal adjustment
- Parking and transport position of the handlebars
- Fixing points when transporting the machine
Fig. 3: Accelerator lever position
1 STOP position
The engine is not running.
• Engine switch-off.
• Engine shutdown.
• Refuelling.
• Machine transport.
3 “Rabbit” position MAX
The engine runs at its maximum speed.
• Working position
2 “Turtle” position MIN
The engine runs at its idle speed.
• Short break.
4 Position CHOKE
The engine choke is engaged.
• Cold engine start.
Fig. 4: Control elements Fig. 5: Safety pictogram - Combined sticker
Fig. 6: Safety pictogram – Disc spinning
- Position on the machine
Fig. 7: Safety pictogram – Machine travel
- Position on the machine
Fig. 8 :Safety pictogram - Service and parking brake
- Position on the machine
Fig. 9: Safety pictogram - Direction of rotation arrow
- Position on the machine
Fig. 10: Safety pictogram - Dangerous area Fig. 11: Machine Working Width
Fig. 12: Connection of the Sulka AV-650 Fig. 13: Lubrication points - bowden cables
Fig. 14: Lubrication points - pins Fig. 15: Lubrication points - pin
Fig. 16: Lubrication points - bowden cable divider
Fig. 17: Lubrication points - transmission
inspection hole plug
Oil dipstick inserting Oil level
Fig. 18: Moving blade assembly 1 Mowing blade
2 Screw
3 Nut
4 Washer
5 Rubber ring
6 Upper disc
7 Lower disc
Fig. 19: The route of the belts and their
guide elements
1 Wheel travel V-belt
2 Engine pulley
3 Transmission pulley
4 Wheel travel tensioning pulley
5 Cutting disc drive V-belt
6 Cutting disc pulley
7 Cutting disc drive tensioning pulley
8 Guide element
Fig. 20: Wheel travel pulley adjusting screw;
lubrication point
Fig. 21: Wheel travel pulley adjusting screw Fig. 22: Cutting disc pulley adjusting
element
Fig. 23: Cutting disc automatic brake
adjusting screw; lubrication point
Fig. 24: Brake pad pressure adjustment nut Fig. 25: Service and parking brake adjusting
screw
Fig. 26: Machine Assembly Procedure
Fig. 27: Tools and accessories - not part of
the machine
Spark plug spanner 21 mm (3/8“)
Ratchet handle 3/8“
VARI canister Ord. No. 3562
HONDA fuel stabiliser Ord. No. 08CXZ-FSC-250
Briggs & Stratton Fuel Fit™ fuel stabilizer (Ordering No. 992381)
Hour meter VARI POWERMETER Ord. No. 4227
Set of spare blades Ord. No. 1005900200 - use only 4 pcs of this set
Table 41: Figure caption translations
55
