Volta Air Technology Owner’s Manual
Van Refrigeration & Freezer Unit
7
CONFIDENTIAL
Technical Specifications
Model
Pluto
Pluto +
Voltage
12V
Refrigerant
R134a
Refrigerant weight
1.3 kg (2.8 lbs)
1.9 kg (4.2 lbs)
Cooling capacity
+541
2100 W (7200 BTU/H)
3200 W (11000 BTU/H)
0 32
1700 W (5800 BTU/H)
2600 W (8900 BTU/H)
-15 (5
700 W (2400 BTU/H)
1100 W (3800 BTU/H)
Heating option
Hot gas heating
Heating capacity
1000 W (3400 BTU/H)
1500 W (5100 BTU/H)
Compressor type
12V DC Brushless Electrical
24V DC Brushless Electrical
Evaporator fan speed
950m³/h (560 CFM)
1380 m³/h (810 CFM)
Condenser fan speed
750m³/h (440 CFM)
980m³/h (580 CFM)
Working current
12V 85A
12V 128A
Max current
12V 110A
12V 168A
Condenser dimensions
1100 x 800 x 217 mm (43.3 x 32.8 x 8.5 in)
Condenser weight
30 kg (66 lbs)
35 kg (77 lbs)
Evaporator dimension
766 x 530 x 153 mm (30.2 x 20.9 x 6 in)
Evaporator weight
13.5 kg (29.7 lbs)
16 kg (35.2 lbs)
