Vatech A9 Technical Manual

Vatech A9 (PHT-30CSS)
Technical manual
VDH-TeM-098
149 / 214
COPYRIGHT© 2020 VATECH.
ALL RIGHTS RESERVED
2. CEPH Geometry Calibration
2.1. Lateral Mode Start Position Setting
1. Identify the starting position using the CEPH standard phantom.
2. Attach 0.8T of Cu in front of the collimator and set the exposure condition to 80kVp 10mA.
3. Attach CEPH standard phantom to the ear rod, click the console software as shown in the
picture below, and capture the Normal LAT Mode.
5. Choose the Ready button.
1. Choose the CEPH mode
2. Choose the High resolution.
3. Choose the Lateral.
4. Choose the Confirm button.
