4. Operation
EzRay Air Wall (VEX-S300W) User Manual 23
3. After tooth type selection, the patient type should be selected. When the
Adult/Child selection area flickers, turn the jog dial to select the patient type. To
see the Control Panel after selection, refer to the figure below.
After patient type selection
Patient Type
Symbol Type
Adult
Child
After the tooth type and patient type are selected, the
exposure time is automatically displayed.
4. If you want to change the exposure time, turn the jog dial to adjust the exposure
time from 0.05 to 0.5 s. (increments: 0.01 s)
If you press the jog dial after adjusting the exposure
time in Manual Mode, the exposure time is returned to
the default setting.
To save the exposure time as default in Manual Mode,
press and hold the jog dial for about 3 seconds.
