4. Operation
EzRay Air Wall (VEX-S300W) User Manual 29
ENGLISH
 Maxillary Canine
The x-ray beam is directed downward at 45°.
Teeth Angle of inclination
Canine Maxilla +45˚
 Mandibular Canine
The x-ray beam is directed upward at 20°.
Teeth Angle of inclination
Canine Mandible -20˚
